Main
| Range of product | ConneXium |
| Product or component type | Ethernet TCP/IP managed switch |
| Concept | Transparent Ready |
| Communication port protocol | Ethernet TCP/IP |
| Port Ethernet | 100BASE-FX - 2 port(s) fiber optic 10BASE-T/100BASE-TX - 6 port(s) copper cable |
| Maximum number of switches in cascade | Unlimited |
Complementary
| Integrated connection type | Duplex SC fiber optic Shielded RJ45 copper cable |
| Transmission support medium | Twisted shielded pairs cable CAT 5E for copper cable Multimode optical fiber for fiber optic |
| Maximum cable distance between devices | 100 m copper cable |
| Attenuation | 11 dB (62.2/125 µm) 8 dB (50/125 µm) |
| Ethernet service | Multicast filtering SNTP client SMTP V3 IGMP Snooping Configuration via web server Secure port Data stream control VLAN Rapid Scanning Tree Protocol (RSTP) Priority port FDR |
| Maximum number of switches in a ring | 50 |
| Redundancy | Redundant power supplies Ring coupling Redundant single ring |
| [Us] rated supply voltage | 12...48 V |
| Supply voltage limits | 10…60 V DC SELV |
| Power consumption in W | 12 W |
| Electrical connection | 2 removable connectors 2 ways power supply |
| Mounting support | 35 mm symmetrical DIN rail |
| Marking | CE |
| Local signalling | 2 LEDsP1 P2 power supplies: 1 LEDfault: 1 LEDring manager: 1 LEDstand-by: 1 LED per channelcopper port activity: 1 LED per channelcopper port status: |
| Alarm output | 2 voltfree contact 1 A |
| Alarm function | Power supply fault High temperature Data link status |
| Ethernet cabling system | TF switches |
| Width | 120 mm |
| Height | 137 mm |
| Depth | 115 mm |
| Net weight | 1 kg |
ConneXium Extended Switch 6TX / 2FX-MM
